The Lockwood Onyx range incorporates advanced security and safety features making this product the ideal choice for sliding patio door applications.
Style and Function
This range takes design cues from contemporary architectural styling and complements several of Lockwood's most popular levers to provide a harmonious look and feel throughout the home. The functionality of the Onyx range has been enhanced by the intuitive operation of the unique sliding snib and the innovative LockAlert feature that indicates the lock status at a glance.
Application
Surface mounted lockset suitable for use with most aluminium and timber sliding doors. The flexible chassis coupled with innovative design features results in a non-handed product that is extremely easy to install and suitable for new and most retrofit applications.
Features
- Twin locking beaks for added security
- Door Close Detect button (DCD) anti slam feature protects locking beaks from accidental damage
- LockAlert indicator shows lockset status at a glance
- DualSelect enables two stage key locking
- Safety Release function minimises the risk of being locked in
- Ergonomic sliding snib with intuitive downward motion to unlock
Strength and Durability
Made to the highest quality levels, the Onyx range satisfies the Australian Standard requirements for strength and durability.
Product Range
A wide selection of furniture options are available in the Onyx range to suit various sliding door applications. The range includes internal D handles and slim pulls and a variety of external furniture and strike options.
Door Thickness
Door thickness range 19mm to 50mm with the standard screw fixing pack provided.
Longer screws and tailbars are available upon application.
Fixing
Surface mounted lockset with concealed fixing.
Industry standard 82mm pitching centres.
Handing
Field selectable handing enables selection of handing during installation.
Keying
Standard Keying
- Supplied individually keyed with two keys per lock
- 78,000 key combinations
- Key blank KB2015P
Restricted Special Keying
- Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.
Materials
- Zinc diecast construction
- Brass cylinders (Satin Chrome Pearl finish)
Standards
Conforms to Australian Standard AS4145.2:2008. Mechanical Locksets for Doors and Windows in Buildings.
- Physical security - S4
- Durability - D8
Standard Finishes
- Black Powdercoat BLK
- Silver Powdercoat SIL
- White Powdercoat WH
- Satin Chrome Pearl SP
- Other plated and powdercoated finishes available as special order
|
